Audio USB Interface Studio 22 + Die Prodipe Studio 22+ ist eine kompakte USB-Audio-Interface für Studio- und Live-Anwendungen. Sie bietet einen XLR/Klinke-Kombieingang, Stereo-Ein- und Ausgänge sowie hochwertige Wandlung durch einen USB-DAC. Dank ASIO2-Treiber ermöglicht sie geringe Latenz und professionelle Audioqualität. Mit 48V-Phantomspeisung eignet sie sich für Mikrofone und Instrumente. Die Schnittstelle ist leicht, portabel und funktioniert sowohl mit Windows- als auch macOS-Systemen. Sie kann zudem eigenständig als Controller genutzt werden. Ideal für Musiker, Podcaster und Heimstudios. Specification Power supply:USB (type A/B cable) Autonomous power supply possible Via USB charger (not supplied Weight: 500gr Compatibility:macOS (Apple CoreAudio) Windows (Prodipe ASIO 2.0 Input:1 x XLR/Jack combo 1 x stereo dual Jack 1 x stereo “BUS” (via USB) Output:1 stereo dual Jack 1 stereo headphone 1 stereo “BUS” (via USB) Phantom Power: Yes Dimensions (HxWxD): 52mm x 109mm x 104mm Accessories supplied: USB cable
STC-3D MK2 Lanen The STC-3D MK2 Lanen is one of the only static mics on the market equipped, with a truly large 34mm capsule and a double 1-inch gold-plated diaphragm, in this price range. Most other brands talk about a "wide" membrane for 16-19mm capsules, and the difference is sizable!. Specification Microphone's range : Vocal mics, String instruments mics, Wind instruments mics, Brass instruments mics, Accordions and bandoneons mics, Battery mics, Live mics , Studio mics Type of mic : Condenser mics Delivered with : clip and storage bag Dimensions : ø 54 x 201 mm Directivity : Uni/Bi/Omni Impedance :output 200„¦±30% (at 1 kHz) Weight : 590g Sensitivity : -31dB/-34dB/-35dB±2dB(0dB=1V/Pa at 1kHz) Frequency response : 20Hz-20kHzSignal - noise : 80/79/78dBWidth capsule : large dual diaphragm (34 mm) with 1" diaphragmLow pass filter : 10 dBMax. SPL input : 130dB (at 1kHz ‰¤1% T.H.D) - 140dB (with 10dB pad)Self noise : 14/15/16dB ALoad impedance :‰¥1000ΩPower supply : 48V DC Phantom Curves:
ST-USB Lanen Studio mic with audio card. If you take a condenser capsule that has been optimised for vocals and instrument and then build an audio chipset into the mic's electronics, the end product is a studio mic that behaves like a separate audio input, but retains the level of sensitivity, resolution and accuracy you would expect from a studio mic. Unlike other USB microphones on the market, the ST-USB is shipped with an ASIO driver letting you use it in all your ASIO software, and not only in a basic multimedia environment. Microphone's range : Vocals mics instruments mics, Wind instruments, Brass instruments mics, Accordions and bandoneons mics,Multimédia and video mics, Studio micsCondenser microphones Studio / Live Kind of microphone : high quality condenser capsule Brand : Prodipe Directivity : cardioid Sensitivity : -35dB(0dB=1V/Pa at 1kHz) Pression max. SPL : 135dB (at 1kHz 1% T.H.D) Frequency response : 20Hz-20kHz Curves
Prodipe Condenser microphone unidirectional Microphone's range : Condenser microphones Studio / Live Instrument microphones Kind of microphone : condenser Brand : Prodipe Power supply : 48V DC phantom (±5V) Directivity : Cardioid Impedance : Output 500„¦±30% (at 1 kHz) Load impedance :‰¥ 1000„¦ Weight : 105 g Sensitivity : -38dB±2dB(0dB=1V/Pa at 1kHz) Low frequency attenuation : 100Hz/oct 12dB Self noise : ‰¤22dBA (IEC 581-5) Max. SPL input : 134dB (at 1kHZ‰¤1% T.H.D) Signal - noise : 20dB A (IEC 581-5) Frequency response : 30Hz-18kHz
